Product Brand: Coates
Coates Spa Heaters are intended for use on spas or hot tubs having a forced water circulation system. The stainless steel tank is designed to optimize heat transfer by directing the water flow over the incoloy elements efficiently.
The built in flow switch prevents operation when there is no water flow and allows operation at flow rates between 15 GPM to 80 GPM. Higher flow may damage the heater. An external bypass should be installed to limit the flow to within this range.
- Electronic Spa Heater Standard Features Include the following: incoloy heating elements, digital thermostat, manual reset high temperature limit, flow switch, heavy duty contactors plus element & flow "on" lights
- Piping connections 1-1/2" x 2" union connections for PVC pipe
- Spa Sizing determine your spa capacity in gallons (length x width x average depth x 7.5) Spa sizing is based on an insulated covered spa. Assumes spa is covered when not in use. Formula does not account for heat loss with variations in actual heat-up time.
-
Physical Placement The Coates Spa Heater is suitable for indoor or outdoor installation. The heater should be securely mounted to a smooth, flat surface. It may be conveniently located next to the filtration equipment. Leave minimum clearances of 9 inches on the left for element removal, 12 inches on the front
for maintenance, 6 inches on the back for service entrance and the right side will be determined by the plumbing configuration used.
Choose the equipment that suit your needs. The Coates Electric Spa Heater comes in one (1) model variant with the product specification listed below:
CM12411ST: Heater, Electric, Coates 11 KW 20-80 GPM (76-303 LPM)
12411ST Electric Spa Heater 11.0 KW
(Heater KW/Volt Rating: 11 at 240 VAC; No. & KW of Heating Elements : 2 at 5.5 KW; Heater Current Rating: 46 AMPS; Recommended Circuit Rating: 60 AMPS; Recommended Supply Wiring: #4 AWG ; BTU'S P/H: 37,543; Shipping Weight: 19 lbs.)
